EL1 series luminescent screens make it possible to visualize infrared laser radiation from systems with large-aperture beams in the visible spectral range. Due to the polymer base, the EL1 luminescent screens can work in the field under various types of precipitation.

Features:
- High moisture resistance and high mechanical characteristics;
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 ^оC to more than +50 ^оC;
- The broad spectral range of 0.75 - 1.5 μm allows to visualize the radiation of different commercial lasers;
- High spectral sensitivity;
- Custom sizes are available.

Polymer Type: IR1
Screen area, сm: 70х70
Absorption Spectral Ranges, μm: 0,75-1,5
Damage Threshold, mW/cm²: >700
Spectral Sensitivity, mW/mm²: <1 (@808 nm, 980 nm, 1450 nm)
Color of Emission: Red-orange
Charging Required for Emission: Yes

EL2 series luminescent screens make it possible to visualize infrared laser radiation from systems with large-aperture beams in the visible spectral range. Due to the polymer base, the EL2 luminescent screens can work in the field under various types of precipitation.

Features:
- High moisture resistance and high mechanical characteristics;
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 ^оC to more than +50 ^оC;
- The broad spectral range of 0.75 - 2.1 μm allows to visualize the radiation of different commercial lasers;
- High spectral sensitivity;
- Custom sizes are available.

Polymer Type: IR2
Screen area, сm: 70х70
Absorption Spectral Ranges, μm: 0,75-2,1
Damage Threshold, mW/cm²: >700
Spectral Sensitivity, mW/mm²: <1 (@808 nm, 980 nm, 1450 nm), <5 (@1940 nm)
Color of Emission: Red
Charging Required for Emission: Yes

EL3 series luminescent screens make it possible to visualize infrared laser radiation from systems with large-aperture beams in the visible spectral range. Due to the polymer base, the EL3 luminescent screens can work in the field under various types of precipitation.

Features:
- High moisture resistance and high mechanical characteristics;
- Screens are able to work in the field under various weather conditions;
- A wide temperature range of operation from -40 ^оC to more than +50 ^оC;
- The broad spectral range of 0,78-1,07; 1,45-1,64 μm allows to visualize the radiation of different commercial lasers;
- High spectral sensitivity;
- Custom sizes are available.

Polymer Type: IR4
Screen area, сm: 70х70
Absorption Spectral Ranges, μm: 0,78-1,07; 1,45-1,64
Damage Threshold, mW/cm²: >700
Spectral Sensitivity, mW/mm²: <2 (@808 nm, 980 nm, 1450 nm)
Color of Emission: Green
Charging Required for Emission: No
