Alignment Targets

AT series alignment targets are laser beam visualizers shaped as discs 25.4 and 50.8 mm in diameter. They fit standard optomechanical mounts and let you align laser systems with minimal intervention in the optical setup. The polymer base makes the targets water-resistant and damage-resistant.

8 models25.4 and 50.8 mm discs0.25–2.1 µmstandard mountscustom mount on request

Model comparison

Click a model to open its page with a description and photos.

ModelWorking rangeArea diameterDamage thresholdGlowPrice
Alignment Target AT-UV-10.25–0.45 µm50.8 mm>700 mW/cm²—7 750 ₽
Alignment Target AT-UV-20.25–0.45 µm25.4 mm>700 mW/cm²—3 750 ₽
Alignment Target AT-IR1-10.75–1.5 µm50.8 mm>700 mW/cm²Red-orange7 750 ₽
Alignment Target AT-IR1-20.75–1.5 µm25.4 mm>700 mW/cm²Red-orange3 750 ₽
Alignment Target AT-IR2-10.75–2.1 µm50.8 mm>700 mW/cm²Red7 750 ₽
Alignment Target AT-IR2-20.75–2.1 µm25.4 mm>700 mW/cm²Red3 750 ₽
Alignment Target AT-IR4-10.78–1.07 / 1.45–1.64 µm50.8 mm>700 mW/cm²Green7 750 ₽
Alignment Target AT-IR4-20.78–1.07 / 1.45–1.64 µm25.4 mm>700 mW/cm²Green3 750 ₽

Prices are per item, in US dollars.

Shipping from our warehouseWe ship from our warehouse in Saransk, Russia. Terms are on the Delivery and Payment page.
OrganizationsBank transfer by invoice
Private customersOrder via AliExpress
DeliveryAny transport company or pickup

Questions and answers

Which mounts do the targets fit?

The 25.4 and 50.8 mm (1 and 2 inch) diameters fit standard optomechanical mounts. We can make a specialized mount to order.

Which target series should I choose?

UV — for ultraviolet 0.25–0.45 µm, IR1 — 0.75–1.5 µm, IR2 — 0.75–2.1 µm, IR4 — 0.78–1.07 and 1.45–1.64 µm.

Do the targets need light charging?

UV, IR1 and IR2 targets need charging with visible light or daylight. IR4 targets work without charging.

Need help choosing?

Tell us about your laser — wavelength, power and beam size. We will pick a suitable model or make a visualizer of the size you need.
